RT7-ZZ-0032 1000 Base-T 10p8c Integrated Magnetic Jacks Ethernet Port RJ45 Connector

Product Categories

LINK-PP INT'L TECHNOLOGY CO., LIMITED

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: RT7ZZ0032 1000 BaseT 10p8c Integrated Magnetic Jacks Ethernet Port RJ45 Connector
Brand: LINK-PP
Price: 1 USD

Brand Name : LINK-PP

Model Number : RT7-ZZ-0032

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000

Price : Supportive

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 4200K-PCS/Month

Delivery Time : Stock

Packaging Details : 50pcs/tray,1200pcs/carton

Part Number : LPJG16305BENL

speed : 10/100/1000 Base-T

OperatingTemperature : 0°c~70°c

LED : Green/Yellow

Archivi Disponibil : PDF/3D/ISG/Stp/Step/Datasheet/Touchstone Format/S-parameters

Lifecycle : More than 20Years

Contact Now

RT7-ZZ-0032 1000 base-t 10p8c Integrated Magnetic Jacks Ethernet Port RJ45 Connector

RT7-ZZ-0032 1000 Base-T 10p8c Integrated Magnetic Jacks Ethernet Port RJ45 Connector

Single Port RJ45 Female Connector with 10/100/1000 Base-T Integrated Magnetics, Green/Yellow LED, Tab Up, RoHS
LINK-PP Part Number:	LPJG16305BENL	Other Part Number	RT7-ZZ-0032
Part Status	Active	Connector Type	Jack
Number of Positions/Contacts	10p8c (RJ45, Ethernet)	Application-Lan	Ethernet(NoN PoE)
Number of Ports	1x1 Port	Speed	10/100/1000 Base-T
Latch	Down	Cores per Port	12
Orientation	90° Angle (Right)	PCB Mount Angle	SIDE ENTRY
Shield EMI Tabs	Without	LED Option	Without
PCB	FR4	PCB Retaining Post	T POST
Package Height (Inches/mm)	0.528/13.45	Package Length (Inches/mm)	0.839/21.25
Package Width (Inches/mm)	0.626/15.95	Temperature	0℃ TO 70℃
Bst Circuit	Yes	AutomDX	YES
Diodes	No	Contact Mating Area Plating	GOLD 6u"/15u"/30u"
Turns Ratio RX/TX	1CT:1CT	Configuration RX/TX	T,C

RT7-ZZ-0032 1000 Base-T 10p8c Integrated Magnetic Jacks Ethernet Port RJ45 Connector
