ARJM14A1-805-AB-EW2 1X4 Port Ethernet Multi - Port Rj45 MagJack with 2.5G Base-T

Name: ARJM14A1805ABEW2 1X4 Port Ethernet Multi Port Rj45 MagJack with 25G BaseT
Brand: LINK-PP
Price: 0.5 USD

Wholesale ARJM14A1-805-AB-EW2 1X4 Port Ethernet Multi - Port Rj45 MagJack with 2.5G Base-T from china suppliers

Brand Name : LINK-PP

Model Number : ARJM14A1-805-AB-EW2

Certification : UL,RoHS,Reach,ISO

Place of Origin : Guangdong,China

MOQ : 50/500/1000/25K

Price : $0.5-$3.5

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 180K/Month

Delivery Time : Stock

Packaging Details : Tray

Spec : ARJM14A1-805-AB-EW2

Equivalent : LPJXXXXNL

I/O : 4x 2.5G Base-Tx

Mounting : Through Hole PCB

Original Munafactuer : LINK-PP

File : PDF/3D/ISG/Stp/Step/Datasheet

Contact Now

ARJM14A1-805-AB-EW2 1X4 Port Ethernet Multi - Port Rj45 MagJack with 2.5G Base-T

Shielded 1x4 Port RJ45 Magjack Connector with 2.5G Base-T Integrated Magnetics , Green/Yellow LED,Tab Down,RoHS
LINK-PP Part Number	LPJGxxxxNL
Abracon LLC Part Number	ARJM14A1-805-AB-EW2
Application-Lan	ETHERNET(NoN PoE)
AutomDX	YES
Bst Circuit	YES
Configuration RX	T,C
Configuration TX	T,C
Contact Mating Area Plating	GOLD 6u"/15u"/30u"
Cores per Port	8
Diodes	NO DIODES
LED Option	Green/Yellow LEDs
Latch	TAB Down
Number of Ports	1X4
PCB	FR4
PCB Mount Angle	SIDE ENTRY
PCB Retaining Post	T POST
Package Height (Inches)	0.535
Package Height (mm)	13.60
Package Length (Inches)	0.839
Package Length (mm)	21.30
Package Width (Inches)	2.327
Package Width (mm)	59.10
Pin Type	THT SOLDER
RoHS Compliant	YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search	YES
Shield EMI Tabs	WITH
Speed	2.5G Base-T
Temperature	-40°C ~ 85°C
Turns Ratio RX	1CT:1CT
Turns Ratio TX	1CT:1CT
