0826-1G1T-32-F Rj45 Modular Jack Gigabit Circuit W/Led's Shielded LPJK4036AWNL
- Designed for network interface card application.
- Designed to meet IEEE802.3u requirement.
- Available in all turn ratios used by LAN ICmanufactures.
- Simplest magnetic component to place androute on PCB.
- Conserves minimizing PCB space.
- 10/100/1000 gigabit ethernet
- Magnetics Rj45
- Rj45 integrated magnetics
- LED optional , EMI-finger Optional
| Part Number | 0826-1G1T-32-F | Latch | Tab up |
| Cross Compatible | LPJK4036AWNL | PCB Mount Angle | SIDE ENTRY |
| Manufacturer | LINK-PP | Shield EMI Tabs | WITH |
| Speed | 1000 Base-T | Number of Port | 1 |
| LED | GREEN/GREEN | Turns Ratio (Np:Ns) | 1:1; 1:1 |
LINK-PP Established in 1997,is worldwide leader in magnetic telecom,networking components and optical transceiver modules design and manufacturing. With an extensive line of state-of-the-art catalog products as well as custom capabilities, LINK-PP is a global supplier magnetic telecom,networking components and Optical Transceiver Modules,the OEM and ODM are welcome.
LINK-PP,there are 2600 staff at present. With the abundant productive capacity of 6000k per month, we are able to deliver the goods within the short time. Moreover,we can provide the professional complete solution for magnetic components and strong technical support as well. Our products are widely used in networking and communication equipments such as HUB,PC card, Switch, Router ,PC Main board, SDH,PDH,IP Phone, xDSL modem.
Committed to bringing the highest possible level of compliance to international standards, all sites are ROSH6, ISO9000:2008 ISO14001:2004, UL,REACH ,CE, FCC,TUV,FDA Registered.
